MotionFX

Create Smears and Trails with a Couple Clicks!

MotionFX is a tool for adding emphasis to motion or creating animation style smears. It take only a couple seconds to set up, and in most cases requires no manual cleanup. It has four unique modes and can be used for motion graphic-esque renders, NPR renders, and more.

Features:

Here are the current features.

Multiple Modes: Not only can you create smears, but there are multiple ways to do it!

Weight Painting: You can control the concentration and intensity of the smears using vertex groups and weight painting

Simple and Easy GUI: Straight to the point, no unnecessary bells and whistles.

Documentation:

Most of the addon is pretty self explanatory, but if there's something you can't figure out it should be explained here.

Inputs:

• Start Frame: The frame that the smears will start on. Default: 0
• End Frame: The frame that the smears will end on. Default: 50
• Frame Step: How many frames before the next smear is calculated. A frame step of one means every frame will be calculated. Default: 1
• Multiplier: How much influence the smears have. Default: 1.0
• Mode: The mode that controls how the smears behave. Default: 1
• Weight Group Name: The name of the weight group used to control displacement. If the name is incorrect, weights will not bake correctly

Operators:

• Clear All Shape Keys: Clears every shape key on the selected object except for Basis. This will affect all shape keys.
• Clear Selected Shape Keys: Clears every shape key after the Start Frame. This will affect all shape keys.
• Clear All Keyframes: Clears every shape key keyframe on the selected object from the start to the end of the timeline. This will leave normal keyframes alone
• Clear Selected Keyframes: Clears every shape key keyframe from the start to the end frame. This will leave normal keyframes alone.
• Create Smears: Creates smears for all frames between the start and end frame using the frame step. This will automatically clear the keyframes and shape keys needed to do the calculations.
• Bake Weights: Uses the current state of the specified weight group to affect future smears until cleared or rebaked.
• Clear Weights: Clears all influence that baked weight groups have on smears.

Scripting Data:

• UI Data: User input data can be accessed through getting mfx_data from any scene object (Ex. bpy.context.scene.mfx_data)
• Object Velocities and Weights: Baked frame velocities can be accessed by indexing either mfx_frame_velocities or mfx_weights from any object (Ex. bpy.context.active_object["mfx_frame_velocities"] )

Questions, Comments, Concerns?

If you have any questions, experience issues, have comments, or think you have info that could help improve the addon, please do not hesitate to ask me. I will try and get back to you as soon as possible.
